Copper 3-Bolt New Installation Drains – Recessed Deck

SKU:
(Select a size)
P-P90361
P-P90362
P-P90364

Premium Copper New Installation Drain Kit with Recessed Deck (Aluminum Clamping Ring & Flip-Top Dome Included)

3" Premium Copper New Installation Drain Kit with Recessed Deck (Aluminum Clamping Ring & Flip-Top Dome Included)

3" stem for 3" (O.D.) pipe - requires coupler

4" Premium Copper New Installation Drain Kit with Recessed Deck (Aluminum Clamping Ring & Flip-Top Dome Included)

4" stem for 4" (O.D.) pipe - requires coupler

6" Premium Copper New Installation Drain Kit with Recessed Deck (Aluminum Clamping Ring & Flip-Top Dome Included)

6" stem for 6" (O.D.) pipe - requires coupler.

Have questions? Feel free to contact us.

Expand Chart

I.D. of the Existing Drain Leader Platinum Drain Size (O.D.) Fits Into Pipe (I.D.) Large End of Seal (Max. Expansion) Note
2″
1 ¾”
2″
NA
Coupler Required
3″
2 ¾”
2.87″ – 3.25″
3.34″
3″ Drain Seal Required
4″
3 ¾”
3.87″ – 4.12″
4.13″
4″ Drain Seal Required
5″
4 ¾”
4.87″ – 5.25″
5.39″
5″ Drain Seal Required
6″
5 ¾”
5.87″ – 6.12″
6.22″
6″ Drain Seal Required

Features & Benefits

  • Available in flat deck sizes of 2", 3", 4", and 6", and recessed deck sizes of 3", 4", and 6" with 12" stem
  • Offered in either flat or recessed deck styles
  • Features an 18" wide deck flange for added coverage
  • Equipped with a heavy-duty cast Aluminum flip-top dome (and clamping ring) for enhanced vandal resistance with powder-coated finish
  • Each roof drain includes a QR code laser-marked on the dome lid for quick registration and easy access to maintenance history
  • Constructed with 24 oz. / 0.05" (1.2mm) prime roofing grade T-2 Copper for drains up to 3", 1.5mm for 5", and 2.0mm Copper for 6" drains
  • Argon-Arc welded with overlapping seams for a clean, solid weld fusion, complemented by Tig-welded ⅜" Stainless Steel bolts to the Copper deck
  • Includes (6) Stainless Steel nuts

Documents

Application

Designed for all types of low-sloped roofs, suitable for both conventional roof membrane systems (without ballast guard) and inverted roof membrane systems (with ballast guard). Compatible with PVC, cast iron, Steel, copper, & other types of leaders.

Standards & Approvals

All Platinum drains are certified by QAI Laboratories to meet ASME 112.6.4 & CSA-B79-08 standards, along with IPC & UPC codes.

Packaging Info

SKUSIZEPACKAGE QTY.DIMENSIONAL WEIGHT LBS. (kg)
P-P90361 3"1 5.1 lb (2.31 kg)
P-P90362 4"1 5.97 lb (2.71 kg)
P-P90364 6"1 8.37 lb (3.8 kg)
SKU: P-P90361
Size:
3"
-
Package QTY:
1
Weight:
5.1 lb (2.31 kg)
SKU: P-P90362
Size:
4"
-
Package QTY:
1
Weight:
5.97 lb (2.71 kg)
SKU: P-P90364
Size:
6"
-
Package QTY:
1
Weight:
8.37 lb (3.8 kg)

Accessories

3-Bolt Aluminum Dome

3-Bolt Aluminum Clamping Ring

Introducing Platinum Roofing Products’ latest advancement: our stainless steel QR drains. These state of the art drains come with an integrated QR code, allowing you to instantly access essential roof information. At Platinum Roofing Technologies, we’re committed to revolutionizing industry standards with our innovative solutions. Simply scan the QR code to easily retrieve comprehensive details about your roof, ensuring you have vital information at your fingertips whenever you need it.
